The mix of glacial tills, thick deposits of advance outwash, and occasional organic layers in Burnaby means compaction control is not a one-size-fits-all job. The marine influence and high rainfall keep moisture levels variable, so the sand cone method becomes a practical call for verifying in-situ density right after the sheepsfoot roller passes. We run the test according to ASTM D1556-16, using a calibrated sand density cone and a consistent pouring height to avoid any operator bias. For fills where the material is coarse or the surface is uneven, we often pair the field density test with a plate load test to directly check bearing capacity under the actual overburden. The whole point is catching soft spots or wet layers before they get buried under the next lift.
A difference of just 2% in compaction can mean the difference between a stable fill and a future settlement call a year later.
Service characteristics in Burnaby
Typical technical challenges in Burnaby
Burnaby's rapid suburban growth in the 1970s and 80s pushed development onto former agricultural lowlands and stream channels. Those areas often contain soft compressible soils that were never properly compacted. If a field density test shows compaction below 95% of the Proctor maximum, the risk of differential settlement under a slab-on-grade or a patio is real. We have seen cases where a single wet layer of about 0.3 m caused visible cracking in a townhouse foundation within two years. The sand cone method catches these issues before the concrete is poured. It is cheap insurance for any site with engineered fill.
Our services
We provide the full compaction control package for Burnaby projects, from the sand cone test on site to the lab verification. Two main service lines we offer:
In-Situ Density by Sand Cone (ASTM D1556)
Our technician performs the test on your fill lift, computes the dry density, and compares it against the project's Proctor curve. We deliver a field report within 24 hours with the compaction percentage, moisture content, and a pass/fail recommendation.
Compaction Control for Utility Trenches and Backfill
For narrow trench fills in Burnaby's residential streets, we adapt the sand cone test to small-diameter holes (60 mm) and adjust the sand calibration accordingly. We also provide a daily summary of compaction results for the contractor's quality control log.
Frequently asked questions
What is the difference between the sand cone method and the nuclear gauge for field density?
The sand cone method is a direct volumetric test – you physically measure the hole volume and the soil weight, so there is no radiation source or calibration drift. The nuclear gauge is faster (one reading in 1–2 minutes) but requires daily calibration and is affected by surface roughness and soil chemistry. For clay fills in Burnaby, many engineers still prefer the sand cone for its traceability.
How long does a sand cone field density test take on site?
From leveling the spot to finishing the hole backfill, about 20 to 30 minutes per test. If we are doing a series of tests across a large fill area, we budget around 45 minutes per test including travel between locations. The moisture content determination in the lab adds another 2 to 3 hours.
Can you perform the sand cone test on wet or saturated fill?
Yes, but the results need careful interpretation. If the fill is saturated, the sand may collapse into the hole before the test is complete, or moisture can alter the sand density. We handle saturated conditions by pre-drying a small sample for moisture content and using a larger sand cone (0.15 ft³) to reduce edge effects. We always note the moisture condition in the field report.
What is the typical price range for a sand cone field density test in Burnaby?
The typical price for a single sand cone density test on a standard fill lift in the Burnaby area ranges from CA$140 to CA$230 per test. This includes the field technician time, the sand calibration, and the lab moisture determination. Volume discounts apply for projects with more than 10 tests.
How many sand cone tests do I need per lift of fill?
There is no fixed number, but a common guideline is one test per 500 m² of fill per lift, with a minimum of three tests per lift for smaller areas. For critical zones like under footings or near retaining walls, we recommend one test per 200 m². The project geotechnical engineer usually specifies the frequency in the compaction specification.
